Molecular Sieve 5A

Molecular Sieve type 5A is an alkali alumina silicate; it is the calcium form of the Type A crystal structure. The pore size of 5A molecular sieve is about 5 Å . It can absorb all kind of molecular smaller than this size, it is mainly used in separation of the normal and isomerous alkane; pressure swing absorption (PSA) for gases; co-absorption of moisture and carbon dioxide.

Formula: 0.7CaO·0.30Na2O·Al2O3·2.0SiO2 ·4.5H2O

Package

Vacuum packing
Cartons with 25kgs/carton
Paper drums with 25kgs/drum
Steel drums with 120-150kgs/drum, etc. as per customers requirement.

Molecular Sieve type 5A is an alkali alumina silicate; it is the calcium form of the Type A crystal structure. The pore size of 5A molecular sieve is about 5 Å . It can absorb all kind of molecular smaller than this size, it is mainly used in separation of the normal and isomerous alkane; pressure swing absorption (PSA) for gases; co-absorption of moisture and carbon dioxide.

Application

Will absorb, in sequence of absorption rate, C3-C14, C2H5CL, C2H5Br, CH3L, C2H5NH2, CH2CL2CH2Br2, CHF2CL, CHF3, CF4, (CH3)NH2, B2H6CF2CL2, CHFCL2, and CF3CL.

Main absorbing target are carbon dioxide and moisture and it can absorb all the material whose molecular diameter is less than 5A.

Normal paraffin separating process.
Oxygen/hydrogen PSA (Pressure Swing Absorption) process.
Ethanol refinement (moisture, CO2, etc).
Refining SF6 refrigerant for power (removing moisture and hydrocarbon).
The strong ionic forces of the divalent calcium ion makes it an excellent adsorbent to remove water, CO2, H2S from sour natural gas streams, while mini missing COS formation. Light mercaptans are also adsorbed.
Separation of normal- and iso paraffin’s.
Production of high purity N2, O2, H2 and inert gases from mixed gas streams
Static, (non-regenerative) dehydration of insulating glass units, whether air filled or gas-filled.

Technical specification

Regeneration

1. Removing the moisture

You May use the dry gas like nitrogen, the air, the hydrogen, the saturated hydrocarbon and heat the gas up to 150-320 ℃.Firstly you need let the hot gas purge through the molecular sieve bed with the pressure of 0.3-05 kg/m2 for 3 to 4 hours. Then change to dry cold gas for 2-3 hour, at last you need isolate the molecular sieve from air and cool it to room temperature.

2. Removing the organics

You can use the water vapor to take the place of organics, then use the method 1.

You can also use the hot water vapor or inner gas pass through the molecular sieve under the temperature of 200-350℃ (couldn’t use the gas which will explore when to mix with the adsorbed organics).

3. Removing the gas

You can reduce the pressure to regenerate the molecular sieve.

Package

Vacuum packing
Cartons with 25kgs/carton
Paper drums with 25kgs/drum
Steel drums with 120-150kgs/drum, etc. as per customers requirement.

FAQ

1.Can you provide free samples?
We can provide free samples within 1kg.

2.Who will pay the courier fee?
Customers need to pay the courier fee. And we will return this courier fee in our following order.

3.Shall customer customize the package?
Our normal package is good for long distance shipping, however, customer’s special request of the package should be customized.

4.Could customer customize product?
Yes, we can customize products according to the customers’ requirement.

5.What’s your delivery time?
For 1*20gp, delivery time is within 10 days after we get the deposit.

6.How to pay?
T/T, L/C, Paypal or Western Union.

7.What’s your shipping port of loading?
Shanghai, Guangzhou, Shenzhen or according to customer’s request.
