Plastic Q Pack
Plastic Q-Pack used in Biological treatment
Q-pack’s large pore volumes and surface areas make it an ideal media for biological treatment of drinking water. Bio filter processes are excellent for treating raw water containing ammonia, manganese, iron etc. Tests have shown that Q-pack works perfectly in these kinds of processes.
In conventional filtration processes Q-pack can be used in different ways. In dual media filters Q-pack can be used in combination with sand. Tests have shown that Q-pack operates as well as or better than traditional filter media in these types of filters.
Q-pack can not only be used in traditional drinking water treatment, but also in treatment of saline water. In desalination plants one of the most important parts is the pre-treatment process. A-pack is an excellent filter media for use in pre-treatment filters in desalination plants.
Q-pack is suitable for use in different effluent water treatment processes, both for municipal and industrial effluents, such as: Biological treatment, Tertiary filtration, Odour treatment.
Introduction:
Plastic Q-Pack used in Biological treatment
Q-pack’s large pore volumes and surface areas make it an ideal media for biological treatment of drinking water. Bio filter processes are excellent for treating raw water containing ammonia, manganese, iron etc. Tests have shown that Q-pack works perfectly in these kinds of processes.
In conventional filtration processes Q-pack can be used in different ways. In dual media filters Q-pack can be used in combination with sand. Tests have shown that Q-pack operates as well as or better than traditional filter media in these types of filters.
Q-pack can not only be used in traditional drinking water treatment, but also in treatment of saline water. In desalination plants one of the most important parts is the pre-treatment process. A-pack is an excellent filter media for use in pre-treatment filters in desalination plants.
Q-pack is suitable for use in different effluent water treatment processes, both for municipal and industrial effluents, such as: Biological treatment, Tertiary filtration, Odour treatment.
Application
Biological treatment
Physical filtation
Pre-treatment for desalination
Available materials
PP, PE
PVC, CPVC
PVDF, PTFE, PFA and many other materails as according to customer’s requirement
Product specification
| Dimension (mm) | Number per m3 | Bulk density (kg/m3) | Void ratio % | Packing factory (m-1) | Drop point |
| Φ95*82.5 | 1165 | 33.7 | 96.3 | 23 | 388 |
Materials Physical Property
| Performance/Material | PE | PP | RPP | PVC | CPVC | PVDF |
| Density (g/cm3) | 0.94-0.96 | 0.89-0.91 | 0.93-0.94 | 1.32-1.44 | 1.50-1.54 | 1.75-1.78 |
| Operation Temp. (Centigrade) | 90 | >100 | >120 | >60 | >90 | >150 |
| Chemical corrosion resistance | Good | Good | Good | Good | Good | Good |
| Compression Strength (Mpa) | >6.0 | >6.5 | >7.0 | >6.0 | >8.0 | >10.0 |
Package
Woven bags
Jumbo bags with 1cbm/bag
Pallet with 1cbm/pallet
MOQ: min.1cbm
